300kN 600kN 1000KN Automatic Hydraulic Universal Testing Machine
Electro-hydraulic servo universal material testing machine
Microcomputer controlled electro-hydraulic servo universal material testing machine adopts servo motor + high pressure oil pump loading, the main body and control frame separate design. It has the characteristics of simple and convenient operation, stable and reliable operation, stable afterforce and high test accuracy. It is suitable for tensile, compression, bending and shear test of metal, cement, concrete, plastic, coil and other materials. It is an ideal testing instrument for industrial and mining enterprises, commodity inspection arbitration, scientific research units, colleges and universities, engineering quality supervision stations and other departments.
Standard test apparatus
◆ Φ170 or Φ200 compression test fixture set.
◆ 2 sets of round sample clips;
◆ Plate sample clip 1 set
◆ Plate sample positioning block 4 pieces.
Technical specification:
|
Model
|
WE-100B
|
WE-300B
|
WE-600B
|
WE-1000B
|
|
Max. test force
|
100KN
|
300KN
|
600KN
|
1000KN
|
|
Lifting speed of middle beam
|
240 mm/min
|
240 mm/min
|
240 mm/min
|
240 mm/min
|
|
Max. spacing of compression surfaces
|
500 mm
|
600mm
|
600 mm
|
600mm
|
|
Max.stretch spacing
|
600 mm
|
700mm
|
700 mm
|
700mm
|
|
Effective distance between two columns
|
380mm
|
380mm
|
375mm
|
455mm
|
|
Piston stroke
|
200 mm
|
200mm
|
200 mm
|
200mm
|
|
Max. speed of piston movement
|
100 mm/min
|
120mm/min
|
120 mm/min
|
100mm/min
|
|
Round sample clamping diameter
|
Φ6 mm –Φ22mm
|
Φ10 mm –Φ32mm
|
Φ13mm-Φ40mm
|
Φ14 mm –Φ45mm
|
|
Clamping thickness of flat specimen
|
0 mm -15mm
|
0 mm -20mm
|
0 mm -20mm
|
0 mm -40mm
|
|
Max. distance of fulcrum in bending test
|
300 mm
|
300mm
|
300 mm
|
300mm
|
|
Up and down plate size
|
Φ110mm
|
Φ150mm
|
Φ200mm
|
Φ225mm
|
|
Overall dimension
|
800x620x1850mm
|
800x620x1870 mm
|
800x620x1900mm
|
900x700x2250 mm
|
|
Dimensions of oil source tank
|
550x500x1200 mm
|
550x500x1200 mm
|
550x500x1200mm
|
550x500x1200 mm
|
|
Power
|
1.1KW
|
1.8KW
|
2.2KW
|
2.2KW
|
|
Weight
|
1500KG
|
1600KG
|
1900KG
|
2600KG
|
