Air Clean Bench Laminar Air Flow Cabinet for Laboratory for Medical Use
- Product Description
Air Clean Bench Laminar Air Flow Cabinet for Laboratory for Medical Use
lean bench is widely used in pharmaceutical, biochemical, environmental monitoring, and electronic instrumentation, and other industries, providing local clean working environment.
Characteristics:
▲ Vertical air flow
▲The shell is made of high quality steel plate,with surface of electrostatic spraying,attractive appearance.▲ Workspace is made of high quality 304 stainless steel, the transparent glasses side panels are on both sides, firm and durable, the working area is simple and bright.▲ The machine adopts the centrifugal fan, stable, low noise, and blowing rate is adjustable to ensure that the workspace is always in perfect condition.▲The top equiped with lighting and sterilization devices.
| Model | VD-650 |
| Neatness class | 100class(US federation209E) |
| Average wind velocity | 0.3-0.5m/s (There are two levels for adjusting,and the recommend speed is 0.3m/s ) |
| Noises | ≤62dB(A) |
| Vibration/half peak value | ≤5μm |
| Lllumination | ≥300Lx |
| Power supply | AC, single-phase 220V/50HZ |
| Maximum power consuming | ≤0.4kw |
| Specification and quantity of the fluouescent lamp and the urltraviolet lamp | 8W,1pc/8W,1pc |
| Specification and quantity of the high efficiency filter | 610*450*50mm,1pc |
| Size of working area(W1*D1*H1) | 615*495*500mm |
| Overall dimension of the equipment(W*D*H) | 650*535*1345mm |
| Net Weight | 50kg |
| Packing size | 740*650*1450mm |
| Gross weight | 70kg |
| Model | CJ-1D | |
| Cleanliness | ISO5class(100class@≥0.5μm) | |
| Number of colony | ≤0.5pc/Vessel(dia.90mm)*hour | |
| Mean wind velocity | 0.30-0.60m/s | |
| Noise | ≤62dB(A) | |
| Vibration in half-peak | ≤3μm | |
| Lllumination | ≥300Lx | |
| Power | 220V 50HZ | |
| Maximum power dissipation | 0.3KVA | |
| Size of working area | W1*D1*H1 | 700*500*500mm |
| Overall dimension of the equipment | W*D*H | 850*575*1565mm |
| Specification and quantity of the high efficiency filter | 695*475*50mm,1pc | |
| Specification and quantity of the fluouescent lamp or urltraviolet lamp | 8W,1pc | |
| Proper persons | Single | |
