Cement Curing Bath with Cooler Unit

Curing Bath with Cooler Unit

This multi-purpose unit, is used to cure in water cement specimens 40x40x160 mm.It is made of stainless steel.The cooler unit is located under the water bath. Complete with re-circulating unit for temperature uniformity.

YSC-104 stainless steel cement curing trough

This product will conduct water curing for cement specimen in conformity with international standards GB/T17671-1999 and ISO679-1999 and can ensure that the curing of the specimen

is performed within the temperature scope of 20°C±1C.This product is made of stainless steel and

microcomputer is adopted to display the control.It is characterized by artistic appearance and easy operation.

Technical parameters:

1.power supply:AC220V±10%

2.Volume:40×40×160 test mold,90 blocks x 4 water troughs=360blocks

3.Heating Power:600W

4.Cooling power:330w Freezing Medium:134a

5.Water Pump Power:60W

6.Scope of Constant Temperature:20°C±1°C

7.Instrument Precision:±0.2°C

8.Working Environment:15°C-25°C
