Hot Sale Laboratory Muffle Furnace High Temperature Furnace

Short Description:

Product Detail

Product Tags

Product Description

Hot Sale Laboratory Muffle Furnace High Temperature Furnace

Ⅰ. Introduction

This series of furnace is used for element analyzing in labs, mineral enterprises and science research institutes; other applications include small size steel heating, annealing and tempering.

It is equipped with temperature controller and thermocouple thermometer, we can supply the whole set.

Ⅱ. Main Technical Parameters

Model	Rated power (kw)	Rated tem. (℃)	Rated voltage(v)	Working voltage(v)	P	Heating-up time(min)	Working room size(mm)
SX-2.5-10	2.5	1000	220	220	1	≤60	200×120×80
SX-4-10	4	1000	220	220	1	≤80	300×200×120
SX-8-10	8	1000	380	380	3	≤90	400×250×160
SX-12-10	12	1000	380	380	3	≤100	500×300×200
SX-2.5-12	2.5	1200	220	220	1	≤100	200×120×80
SX-5-12	5	1200	220	220	1	≤120	300×200×120
SX-10-12	10	1200	380	380	3	≤120	400×250×160
SRJX-4-13	4	1300	220	0~210	1	≤240	250×150×100
SRJX-5-13	5	1300	220	0~210	1	≤240	250×150×100
SRJX-8-13	8	1300	380	0~350	3	≤350	500×278×180
SRJX-2-13	2	1300	220	0~210	1	≤45	￠30×180
SRJX-2.5-13	2.5	1300	220	0~210	1	≤45	2-￠22×180
XL-1	4	1000	220	220	1	≤250	300×200×120
