Laboratory Air Clean Bench And Biosafety Cabinet And Fume Hood

Short Description:


Product Detail

Product Tags

  • Product Description

Laboratory Air Clean Bench And Biosafety Cabinet And Fume Hood

Clean bench is widely used in pharmaceutical, biochemical, environmental monitoring, and electronic instrumentation, and other industries, providing local clean working environment.

Characteristics:

▲ Vertical air flow

▲The shell is made of high quality steel plate,with surface of electrostatic spraying,attractive appearance.▲ Workspace is made of high quality 304 stainless steel, the transparent glasses side panels are on both sides, firm and durable, the working area is simple and bright.▲ The machine adopts the centrifugal fan, stable, low noise, and blowing rate is adjustable to ensure that the workspace is always in perfect condition.▲The top equiped with lighting and sterilization devices.

1.

Model VD-650
Neatness class 100class(US federation209E)
Average wind velocity 0.3-0.5m/s (There are two levels for adjusting,and the recommend speed is 0.3m/s )
Noises ≤62dB(A)
Vibration/half peak value ≤5μm
Lllumination ≥300Lx
Power supply AC, single-phase 220V/50HZ
Maximum power consuming ≤0.4kw
Specification and quantity of the fluouescent lamp and the urltraviolet lamp 8W,1pc/8W,1pc
Specification and quantity of the high efficiency filter 610*450*50mm,1pc
Size of working area(W1*D1*H1) 615*495*500mm
Overall dimension of the equipment(W*D*H) 650*535*1345mm
Net Weight 50kg
Packing size 740*650*1450mm
Gross weight 70kg

VD-850

2.

Model CJ-1D
Cleanliness ISO5class(100class@≥0.5μm)
Number of colony ≤0.5pc/Vessel(dia.90mm)*hour
Mean wind velocity 0.30-0.60m/s
Noise ≤62dB(A)
Vibration in half-peak ≤3μm
Lllumination ≥300Lx
Power 220V 50HZ
Maximum power dissipation 0.3KVA
Size of working area W1*D1*H1 700*500*500mm
Overall dimension of the equipment W*D*H 850*575*1565mm
Specification and quantity of the high efficiency filter 695*475*50mm,1pc
Specification and quantity of the fluouescent lamp or urltraviolet lamp 8W,1pc
Proper persons Single

SW-CJ-1G

All-steel clean bench:

Laminar flow cabinet

Clean bench/Laminar flow cabinet
