Small Jaw Crusher

Small Jaw Crusher

We can customize jaw crusher according to user’s requirements.

Uses:

It is used in crushing rock and ore with mid-hardness of units of mine, metallurgy, geology, building material, light industry, chemical industry and testing.

Characteristics:

1. The dental plate is made of high manganese steel with big crushing strength and good result.

2. The output size could be adjusted by regulating screw.

3. It adopts Y90L-4 three-phase motor, safe and reliable.

Technical Data:

Model:150*250.

Max input size: 125mm,

Discharge port adjustment range:10~40mm,

Capacity:1~3 m³/h,

Spindle speed:285 r/min,

Power:5.5KW,380V/50HZ,

Weight:700kg

Reference photos:

Related product:

Model	Voltage(V)	Power	Input size	Output size	Spindle speed	capacity	Overall dimensions	N.W.	G.W.
(Inlet size)		(kw)	(mm)	(mm)	(r/min)	(kg/hour)	(mm) D*W*H	(kg)	(kg)
100*60mm	Three-phase,380V/50HZ	1.5	≤50	2~13	600	45~550	750*370*480	125	135
100*100mm	Three-phase,380V/50HZ	1.5	≤80	3~25	600	60~850	820*360*520	220	230
150*125mm	Three-phase,380V/50HZ	3	≤120	4~45	375	500~3000	960*400*650	270	280

Photos for model100*60,100*100,and 150*125:

Pulverizer(MODEL:FM-1,FM-2,FM-3):

---
